MNP-HELIOS-SYN

Contact us

PRICE: 25.800.000 VNĐ/200L (46/100/150)

HELIOS SYN is high quality compressor oil formulated from synthetic base oil and selected additives designed for using in the system of compressor air or inert gas of big capacity.

Features

  • Anti-corrision and anti-oxidant.
  • High thermal stability.
  • Anti-generated sediment.
  • Excellent ability to break emulsions.
  • Resistance to foaming.
  • Good filter ability.

Technical Standards

DIN 51506 VDL, GM LJ, SAE MS1003-2.

Applications

  • Lubricating and cooling for compressor type of the piston and screw.
  • Lubricating and cooling for pumps which absorb vacuum, inert gas with low vacuum levels.

Technical Data

Technical specifications Test methods 32 46 68
Density at 15oC (Kg/l) ASTM D 4052 0.84-0.86 0.85-0.88 0.86-0.89
Kinematic viscosity at 40oC (mm2/s) ASTM D 445 30-35 44-50 68-73
Viscosity index (VI) ASTM D 2270 Min 130 Min 130 Min 130
Pour point (oC) ASTM D 97 Max -45 Max -45 Max -42
Flash point COC (oC) ASTM D 92 Min 220 Min 230 Min 230
Water content by vol/mass (%V) ASTM D 95 Max 0.03 Max 0.03 Max 0.03
Water separation at 54oC (Phút) ASTM D 1401 10 10 10
Foam sequence I (ml/ml) ASTM D 892 10/0 10/0 10/0
Rotary Pressure Vessel Oxidation Test RPVOT (Phút) ASTM D 2272 2200 2200 2200
Rust test – seawater 24 hrs ASTM D 665B Pass Pass Pass

(The above data is collected as typical figures in general, accepted in production but do not constitute specifications).

Preservation and Safety

  • To put the package in the vertical.
  • Storage temperature should not exceed 60oC.
  • Keep off sparks and flammable materials
  • Store in a covered warehouse.
  • Storage tanks must be covered carefully and away from the risk of contamination.
  • Used oil must be treated properly, don’t pour directly into ditches, water sources.

Packing

  • Bucket of 18 litres, 25 litres and drum of 200 litres.
  • Or package according to customer requirements.
